A powerful and precise 1300 W hot-air desoldering station for professional PCB repair and SMD rework, offering PID temperature control, adjustable airflow (5–200 %), and safety protections.
Here is a well-structured description + features section you can use:
Description:
The FORWARD FW-BF03 / FW-BF04 1300 W Hot Air Desoldering Station is a high-performance rework tool designed for precision PCB repairing, micro-soldering, and SMD desoldering. Equipped with a 1300W ceramic heating core and a high-speed turbo fan, it delivers stable and controllable hot airflow for demanding electronics work.
Key Features:
High Power Heating
Uses a 1300 W ceramic heating core for rapid heat-up and stable temperature.
Temperature range: 100 °C to 500 °C.
Precise Temperature Control
Resistance wire heating + K-type thermocouple sensing.
Micro-computer PID control for stable temperature with ±2 °C accuracy.
Adjustable Airflow
High-performance double-ball vortex fan gives large airflow with high pressure.
Airflow can be adjusted from 5% to 200% for precise control.
Fan speed: ~15,000–18,000 rpm.
Ergonomic and Smart Handle Design
Handle has 3 control buttons to switch memory channels, adjust temperature, airflow, and air mode.
Magnetic switch: remove handle from holder → enters work mode; place back → cooling → standby → saves energy and extends heating element life.
Safety Protections
3-second (3S) fault detection.
Anti-dry burn protection: prevents damage when no airflow or if overheated.
Automatic cutoff in case of fault.
Audible alerts + error codes for: constant temperature, standby, overheat, no-heat, handle drop, etc.
Built-in timer for desoldering: alerts when set time finishes, helping prevent damage to sensitive chips or PCBs.
Memory Presets
Multiple memory channels (for saving commonly used combinations of temperature + airflow).
Build & Design
Adjustable rocker arm stand: angle can be freely adjusted for convenience.
LCD display for temperature / settings.
Handle cable length ~800 mm.
Dimensions: main unit ~174 × 230 × 173 mm; holder ~102 × 159 × 131 mm.
Weight: 3.1 kg for the station, holder ~1.2 kg.
Package Contents
Manual ×1
Power Cord ×1
Hot Air Handle ×1
Multi-function sleeping base / stand ×1
Temperature Cue Card ×1
Nozzles (ultra-low wind resistance) ×5
10.Voltage Options
Available for 110 V or 220 V variants
